Safety beam

The safety sensor beams are designed for automatic door control but are also similarly suited for other applications such as garage doors ,gate operators, etc. as a safety or primary control device where a narrow field of detection is required.
Each set consists of a controller, equipped with two pairs of emitter/detector sensor.

Main Features
• Miniature sensor head & compact controller and Installation flexibility for unlimited applications.
• Single or double Microcells available
• Sensor head can be separated from shielded wire at the plugs for easy installation.
• Available with short or long cables
• Micro processed active infrared
• Low power consumption.
• 12V-24V AC/DC Universal power input.

Input Voltage: 12~24V AC/DC
Technology: Active through infrared beam, Microprocessor
Relay Contacts: NC/NO
Function Indicator: Led (Beam break & Status)
Max Detecting Distance: 5m / 10m
Hold time: 300 ms

Compatible with all automatic door manufacturers like Besam, Dorma, Geze, Kaba, Horton, Record, Stanley, Tormax etc
